Flat Bed Thick Material Trimming Single Needle Sewing Machine With Left Knife
Product introduce
This is a large-mouth sewing machine with a knife (right knife), which can trim the edge material while sewing. The shuttle adopts a vertical standard shuttle. The lubrication method adopts manual lubrication. The machine adopts a sliding rod to take up the thread to form a double-thread lock stitch. The upper and lower shafts are driven by a synchronous toothed belt. The presser foot, feed dog, and needle feed synchronously.
Product advantages
This machine is a cylindrical thick-material sewing machine specially designed for the manufacture of luggage and bags, with solid mechanism and novel shape. The sewing space reaches 260*100mm. Fixed trimming knife holder, straw hat and leather edge for trimming leather.
Applications
Suitable for handbags, toys, luggage, hats, etc.
Product parameter
| model | JL-341LD |
| product name | Edge trimming machine with knife |
| keyword | High - speed automatic trimming sewing machine |
| presser foot lift | 8mm ( by hand ) 13mm ( by knee ) |
| voltage | 220V |
| sewing material | genuine leather,thick fabric |
product details
Parabolic screws, the role of parabolic screws to fix the edging tube frame
Reverse stitch handle
The reverse stitching handle is in a static state during sewing operation. If the sewing material needs to be reinforced, the sewing material will be fed back when the reverse stitching handle is pressed down.
Thread clamp
Adjust the tension of the upper thread.
Adjust the stitch length digital dial
The digital gauge dial can be adjusted in 1-6 steps. The operator can easily rotate the dial to achieve the ideal gauge. Turn clockwise to shorten the gauge, and vice versa.
Cylindrical sewing table
The cylindrical sewing table can sew difficult and complicated operations such as cylindrical bag openings that cannot be sewn by a flat sewing machine. The cylindrical diameter is 70mm.
Pressure adjusting nut
Adjust the pressure of the large and small presser feet; turn clockwise to increase the pressure when sewing thick materials, which can make the machine feed stably and the stitch length is even; on the contrary, when sewing thin materials, reduce the pressure to make the sewing material without wrinkles.
Tool holder on the left
Fixed trimming knife holder, straw hat and leather edge for trimming leather.
